Metal Needle Wheel

The metal needle wheel is a critical component of the encoder. Its surface features dozens to hundreds of minute, uniformly distributed protrusions. Injection moulding represents the most economical method for achieving mass production of this product. We can manufacture precision pin wheels with tooth widths as small as 0.1mm and tooth depths exceeding twice the width, with dimensional consistency across all teeth maintained within ±1%. Furthermore, the pin wheel can be designed as an integrated component with the bearing seat and locating flange, simplifying the encoder's internal structure while enhancing assembly efficiency and concentricity.

Product Parameter (Specification)

Product Feature And Application

The Unique Value of Powder Metallurgy in Encoder Component Manufacturing

（1）Micro-feature Forming Capability: Enables stable mass production of high-precision, high aspect ratio fine tooth profiles at significantly lower costs than CNC or laser machining.

（2）Integrated Moulding and High-Precision Reference: Encoder discs or pin wheels can be formed in a single operation with mounting sleeves, locating flanges and other structures, ensuring exceptional coaxiality and perpendicularity between the sensing section and mechanical mounting reference to minimise system errors.（3）Superior Batch Consistency and Cost-Effectiveness: For encoder discs requiring tens of thousands of lines or pin wheels with numerous micro-teeth, powder metallurgy delivers unparalleled consistency and cost advantages in high-volume production.

Production Details
