Guangming Group will talk about D-hole helical gears today

D-hole helical gear=helical gear+D-shaped shaft hole, is a commonly used structure that combines "smooth helical gear transmission" and "D-hole anti-skid", and is very common in automation, small reducers, and motor matching.

1、 What is a D-shaped hole

The inner hole is not a complete circle, but a circular arc with a straight edge, with a cross-section resembling the letter D.

Milling a flat surface (D-axis) on the corresponding axis, it can be installed and fixed in the circumferential direction without slipping, without the need for keyways, top screws, or glue.

2、 What is a helical gear

The gear teeth form a helix angle (15 ° -45 °) with the axis and are not straight.

Features:

Mesh is a gradual process with low noise, smoothness, high overlap, and high load-bearing capacity.

Disadvantage: It will generate axial force, and the bearing needs to withstand both radial and axial forces.

3、 Advantages and disadvantages of D-hole helical gears

advantage

Non slip: D-hole+D-axis, reliable torque transmission, can be fixed even without keyway.

Easy installation: Simply press or tap into place without adjusting the top thread or applying glue.

Smooth transmission: Diagonal teeth have 5-10dB lower noise than straight teeth, suitable for high-speed/low-noise scenarios.

Compact structure: eliminating keyways and flanges, the wheel hub can be made smaller.

shortcoming

Axial force: Single helical gear operation will push the gear towards one end, and the bearing should be selected to withstand axial force.

Processing is slightly more expensive: both D-holes and helical teeth require specialized tools/processes, which are more expensive than straight tooth circular holes.

Cannot frequently change direction with high torque in both directions: When the impact is large, the straight edge of the D-hole is prone to crushing (plastic gears are more obvious).

4、 Common specifications and coordination

Modulus: 0.5, 0.8, 1.0, 1.25, 1.5, 2.0 (commonly used for small automation).

Pressure angle: 20 ° (standard).

D-hole size: 2mm, 3mm, 4mm, 5mm, 6mm, 8mm, 10mm (matching with motor shaft/output shaft).

Spiral angle: 15 ° -20 ° (balancing stability and axial force).

Rotation direction: Left/Right (one left and one right when paired).

5、 Typical applications

Small motor matching: Output gears for N20, N30, 28BYJ and other motors.

Filling machine/packaging machine: small conveying, bottle shifting, measuring and fine-tuning mechanism (low noise, stable).

Automation equipment: precision transmission, low torque, frequent start stop situations.

Robots/servos: joints, gimbal, fine tuning transmission.

6、 Difference from "herringbone gear" (easily confused)

D-hole helical gear: single helical teeth+D-hole; There is axial force; Simple structure, affordable, and commonly used.

Herringbone gear (double helical teeth): symmetrical helical teeth for left and right rotation; Axial force self offsetting, suitable for heavy load and high speed; Processing is complex, expensive, and bulky.

7、 Key selection points

D-hole size: It must be tightly matched with the D-shaped size of the shaft (interference fit 0.01-0.03mm).

Spiral angle and direction: selected based on speed, noise, and axial force; Pairing requires one left and one right.

Material

Light load: POM, nylon (cheap, noise reducing).

Medium load: 45 # steel, powder metallurgy.

Heavy load: 20CrMnTi carburizing and quenching.

Axial force treatment: Single helical teeth should be equipped with deep groove ball bearings (capable of withstanding a small amount of axial force) or angular contact bearings.
